4V1 Series Aluminum Alloy Solenoid Valve Air Control 5 way 12V 24V 110V 240V

Short Description:

The 4V1 series aluminum alloy solenoid valve is a device used for air control, with 5 channels. It can operate at voltages of 12V, 24V, 110V, and 240V, suitable for different power systems.

This solenoid valve is made of aluminum alloy material, which has excellent durability and corrosion resistance. It has a compact design, small size, light weight, and is easy to install and maintain.

The main function of the 4V1 series solenoid valve is to control the direction and pressure of air flow. It switches the direction of airflow between different channels through electromagnetic control to achieve different control requirements.

This solenoid valve is widely used in various automation systems and industrial fields, such as mechanical equipment, manufacturing, food processing, etc. It can be used to control equipment such as cylinders, pneumatic actuators, and pneumatic valves, achieving automated control and operation.

Send email to us

Product Detail

Product Tags

Technical Specification

Model		4V110-M5	4V120-M5	4V130C-M5	4V130E-M5	4V130P-M5	4V110-06	4V120-06	4V130C-06	4V130E-06	4V130P-06
Working Media		Air
Action Mode		Internal Pilot Type
Position		5/2Port		5/3Port			5/2Port		5/3Port
Effective Sectional Area		5.5mm²(Cv=0.31)		5.0mm²(Cv=0.28)			12.0mm²(Cv=0.67)		9.0mm²(Cv=0.50)
Port Size		Input=Output=Exhaust Port=M5*0.8					Input=Output=Exhaust Port=G1/8
Lubrication		Oil-free lubrication
Working Pressure		0.15~0.8MPa
Proof Pressure		1.0MPa
Working Temperature		0~60℃
Voltage Range		±10%
Power Consumption		AC:2.8VA DC:2.8W
Insulation Grade		F Level
Protection Class		IP65(DIN40050)
Connecting Type		Wiring Type/Plug Type
Max.Operating Frequency		5 Cycle/Sec		3 Cycle/Sec			5 Cycle/Sec		3 Cycle/Sec
Min.Excitation Time		0.05Sec
Material	Body	Aluminum Alloy
	Seal	NBR
